AXM-WEB2 WIFI Ethernet Communication Module

New AXM-WEB2
Mouseover to zoom-in
Acuvim II - WiFi + Ethernet Module
Acuvim II - WiFi + Ethernet Module
Acuvim II - WiFi + Ethernet Module
Acuvim II - WiFi + Ethernet Module
Made in Canada cUL US CE certified 5 year warrantyWiFi

Acuvim II Meter
WiFi + Ethernet Module

AXM-WEB2 Communication Module

AXM-WEB2 provides fast and reliable dual Ethernet ports and WiFi communication channels for Acuvim II Series power meters. Supports a wide range of communication protocols such as Modbus-TCP/IP, HTTP/HTTPs Post, FTP, sFTP, BACnet-IP, DNP3 V2, SNMP V3, IEC61850 2nd edition, SMTP and NTP time synchronization.
  • New FeatureNative support of Ethernet/IP protocol, seamless integration with Allen Bradley and Rockwell Systems
  • New FeatureIEC 61850 protocol 2nd Edition
  • New FeatureIPV6 and IPV4 dual IP network support allows for more connected devices
  • New FeatureCustom Modbus register list to group key parameters continously
  • New FeatureMaintain high availability by RSTP protocol with two ports connect to same subnet
  • New FeatureLog Max, Min and Average on all parameters at all logging intervals
  • New FeatureFirmware OTA update
  • Daisy-chain Ethernet ports (RSTP Protocol)
  • Support for WiFI WPA, WPA2 Enterprise security protocol
  • Remote meter access via SerialNumber.accuenergy.io
  • Dual Ethernet RJ45 port with individual network configuration
  • Dual Ethernet ports and WiFi work simultaneously with different networks and data acquisition systems
  • COMtrade format for waveform capture
  • 8GB onboard memory with 1-second interval datalogging capabilities
  • Industry-leading 100ms and 40ms response rate via Modbus-TCP/IP protocol
  • Secure HTTPS data encryption to cloud server
  • SSL encrypted webserver plus TLS 1.2 compliance for industry-leading cybersecurity standard
  • Metering data backup log to avoid data loss during network downtime
  • Support industrial, utility and substation protocols IEC 61850, DNP 3.0 V2, Modbus-TCP/IP, SNMP, HTTP/HTTPs Post, FTP & SNTP
  • Built-in sFTP server for data-log storage and retrieval.
  • Web accessible graphical display of historical data trends for all parameters for analysis
  • WiFi supports Access Point mode and Station mode for both direct connection/configuration and public WiFi network connection
Downloads:

AXM-WEB2 WIFI + Ethernet Module

Connect Acuvim II Series power and energy meter to the AXM-WEB2 module for WiFi and dual Ethernet capabilities.

Add AXM-WEB2 to Acuvim II Power Meter

AXM-WEB2 module expands Acuvim II energy meters with WiFi and Ethernet communication options. Supports Modbus-TCP/IP, SMPT, HTTPS Post, SNTP protocols and more.

Transmit Fast Encrypted Energy Data to Server
Protect sensitive data communication with secure HTTPS data encryption. Allow only authorized access to owners and managers. Acuvim II can be connected to any facilities’ WiFi network with enterprise-grade authentication.
Cross-Platform Support For Various Devices

Access your Acuvim II power meter anywhere at SerialNumber.accuenergy.io. AXM-WEB2 allow users to access Acuvim II’s web panel remotely without the need for IP and port forwarding or open up firewall with new remote access feature.

Monitor real-time metering data anytime, anywhere with web-accessible devices such as laptop, tablet, and mobile devices.

AXM-WEB2 Features

Fast. Reliable. Secure.

Class-Leading Security
Fully encrypt and authenticate data communication between energy meters and data server. AXM-WEB2 supports leading HTTP web security standard TLS v1.2 and SSL HTTPS encryption. WiFi communication is authenticated through WPA or WPA2 enterprise security protocol.
Reliable Backup Data Logs

Prevent data outages from network downtime or any other possible communication issues. AXM-WEB2 pushes data via HTTP post, HTTPS post, or FTP to your server or energy management system (EMS). Data are logged locally on the module until all data are successfully posted to the server to ensure data integrity.

Fast Modbus-TCP/IP Response Time: 40ms

AXM-WEB2 module provides a fast communication protocol within 40ms that enables Acuvim II series power meters to make real-time updates to key parameters such as line and phase voltage, current and power readings via industry de-facto Modbus-TCP/IP.

Out-of-Box Two-Level User Control

Administration Level ManagementRobust administrative settings that give you full control over how the application will be implemented within your project.
  1. Manage metering settings for voltage wiring, current wiring, real-time reading options and more.
  2. Configure communication for network, E-mail, SNTP, HTTP/HTTPS/FTP Post
  3. Reset data collection
  4. Get the latest firmware upgrades
User Level Monitoring

Easy accessible real-time data for energy managers to monitor and determine power and energy integrity across your project application without compromising unauthorized security.

Easy-To-Use Web Interface

24/7 Data Monitoring

Monitor metering data anytime, anywhere with our user-friendly web interface. Accessible on any browser client and a web-enabled device such as mobile, desktop or tablet no matter where you are.

Time Sensitive

Monitor real-time power metering data and system performance to ensure critical decision-making are made in time crucial environments.

Energy Management

Access full reports to help manage power (kW) and energy (kWh) metering usage, peak current (amp) & power demand cycles, and power quality harmonics to optimize your systems energy efficiency.

Application Support

Professional and friendly support is available to guarantee your project is on schedule and never compromised.
