POWER & ENERGY
METER COMPARISON
No Model Available
No Model Available
No Model Available
Key Specifications
| Mounting | ||
|
|
|
|
| Panel Mount or DIN Rail |
||
| Panel Shop | ||
|
|
|
|
| AcuPanel 9106X Custom Panel |
||
| Real-Time Metering | ||
|
|
|
|
| Phase Voltage, Line Voltage, Current, Power, Reactive Power, Apparent Power, Power Factor, Frequency | ||
| Accuracy Class | ||
|
|
|
|
| ANSI C12.20 class 0.5 IEC 62053-22 class 0.5s |
||
| PQ Compliance | ||
|
|
|
|
| Compliance | ||
|
|
|
|
| UL Listed CE Mark BTL Listed Measurement Canada Approved |
||
| Voltage Input | ||
|
|
|
|
| 400Vac L-N 690Vac L-L |
||
| Current Input | ||
|
|
|
|
| 333mV RCT Rogowski Coil 80/100mA |
||
| Power Supply | ||
|
|
|
|
| 100-415 Vac, 100-300Vdc |
Key Features
| Data Logger | ||
|
|
|
|
| 8MB | ||
| Memory | ||
|
|
|
|
| Power Quality | ||
|
|
|
|
| 2nd - 31st Harmonics | ||
| Ports | ||
|
|
|
|
| RS485 Serial Port | ||
| Input/Output | ||
|
|
|
|
| 18x Digital Input 6x Digital Output 2x Relay Output 15Vdc PSU |
||
| Environmental Rating | ||
|
|
|
|
| NEMA 3 NEMA 4X* |
Communications
| Serial | ||
|
|
|
|
| Modbus-RTU | ||
| Ethernet | ||
|
|
|
|
| Networking | ||
|
|
|
|
| Data Post | ||
|
|
|
|
| Web Server | ||
|
|
|
|
| Wireless Mesh | ||
|
|
|
|
* With protective cover or enclosure.
** Only for Acuvim CL and EL models.
