POWER & ENERGY
METER COMPARISON
No Model Available
No Model Available
No Model Available
Key Specifications
| Mounting | ||
| Panel Mount or DIN Rail Transducer | ||
| Panel Shop | ||
| AcuPanel 9104 AcuPanel 9104X Custom Panel | ||
| Real-Time Metering | ||
| Bi-Directional Energy Measurement, Line to Neutral Voltages, Current, Active Power, Reactive Power, Apparent Power, Power Factor, Load Nature, Frequency | ||
| Accuracy Class | ||
| ANSI C12.20 class 0.2 IEC 62053-22 class 0.2s | ||
| Compliance | ||
| UL Listed CE Mark | ||
| Voltage Input | ||
| 400Vac L-N 690Vac L-L | ||
| Current Input | ||
| 5A/1A 333mV RCT Rogowski Coil | ||
| Power Supply | ||
| 100-415 Vac, 100-300Vdc |
Key Features
| Data Logger | ||
| 8MB | ||
| Power Quality | ||
| 2nd - 31st Harmonics | ||
| Ports | ||
| RS485 Serial Port 2x Ethernet RJ45 Port WiFi Antenna Connector | ||
| Input/Output | ||
| Environmental Rating | ||
| NEMA 3 NEMA 4X* |
Communications
| Serial | ||
| Modbus-RTU BACnet MS/TP |
||
| Ethernet | ||
| Networking | ||
| Data Post | ||
| Web Server | ||
| Wireless Mesh | ||
* With protective cover or enclosure.
** Only for Acuvim CL and EL models.
